Excel and Removing Columns

I had a situation today where I had a spreadsheet that contained hundreds of columns. I only needed five or so of these and I didn’t fancy going through them one-by-one to delete the unnecessary ones. I found the below snipped of VBA on stackoverflow. The code ran almost instantaneously and deleted all columns that I didn’t need. The country names are the columns that I needed to keep. I didn’t change/need the part of the code that deletes cells if they don’t contain the string ‘homer’.

Sub deleteIrrelevantColumns()
    Dim currentColumn As Integer
    Dim columnHeading As String

    ActiveSheet.Columns("L").Delete

    For currentColumn = ActiveSheet.UsedRange.Columns.Count To 1 Step -1

        columnHeading = ActiveSheet.UsedRange.Cells(1, currentColumn).Value

        'CHECK WHETHER TO KEEP THE COLUMN
        Select Case columnHeading
            Case "England", "New Zealand", "India", "South Africa", "Malaysia", "China", "Philippines", "Scotland"
                'Do nothing
            Case Else
                'Delete if the cell doesn't contain "Homer"
                If Instr(1, _
                   ActiveSheet.UsedRange.Cells(1, currentColumn).Value, _
                   "Homer",vbBinaryCompare) = 0 Then
                    ActiveSheet.Columns(currentColumn).Delete

                End If
        End Select
    Next

End Sub

IRELAND-TOWNLANDS

In Ireland, the townland is the smallest unit of land division. They pre-date the Anglo-Norman conquest (source). What I find amazing about them is how prevalent their use is to this day. Where I grew up in Kerry, they are still used, day-in, day-out to give everything from directions to advertise property and house sales. I find this fascinating; what also amazes me is the number of discussions that occur among friends and in the community regarding townlands and their exact boundaries. Until the OSI released the below dataset, any disputes on the boundaries would have to be resolved using someone’s copy of maps from the 19th Century. It is great to be able to solve these using accurate data.

There has been an OSM project ongoing with a few years to map all the townlands of Ireland. The Ordnance Survey of Ireland released the townland boundaries as open data under a creative commons licence. There are no townlands for the cities of Dublin and Cork but they cover the rest of the country. There are 50,380 townlands in this dataset.

Townlands of Ireland

Townlands of Ireland

Because the ArcGIS Online viewer isn’t fantastic, I uploaded the townlands to Carto to view online. I have only uploaded the 50m generalised dataset as the ungeneralised dataset is ~240MB. Below is a Carto web map of the townlands of Ireland. I hope to do some work in the future on these townlands, such as general statistics and such.

ArcPY Data Driven Pages Script

I had a situation at work a few weeks back where an individual needed 180 maps within a few hours. The maps themselves weren’t overly complex, they required satellite imagery as the basemap, some Ordnance Survey mapping overlaid with each map showcasing a particular site (in the Greater London area). I knew I wouldn’t be able to turn these around if I had to export them manually so enter ArcPy and the power of data driven pages in ArcMap.

I used the basic ‘Grid Index Features‘ tool to create the index for the mapbook and I then created the mapbook as normal. I needed each page to only show one site, to achieve this there is a little workaround in ArcMap to white-out irrelevant features.

The next step was to insert dynamic text for each page using a value from the attribute table (this was the layer name). I carried out a spatial join between the polygons (which contained the field with the polygon/page name) and the grid index features so that each grid index polygon would have the page/polygon name as an attribute. I then used this guidance to ensure each page had its own page number.

Although, it would have been possible to export the mapbook from the ‘File’ menu, it would just export one (quite large) pdf with a single filename as opposed to 180 individual PDFs with each having the correct label and title. I then wrote the following python function in order to export each page. If the same file name is exported more than once it appends an underscore and number to the end. It then took about 20 minutes to export the 180 plans, automation for the win!

#Export Data Driven Pages to PDF (Proper Names)
import arcpy, os
def export_pdf_maps():
	strOutpath = r"\\Output_Location"
	mxd = arcpy.mapping.MapDocument(r"\\Example.mxd")
	ucodes = {}
	for pageNum in range(1, mxd.dataDrivenPages.pageCount + 1):
		mxd.dataDrivenPages.currentPageID = pageNum
		pageorder = mxd.dataDrivenPages.pageRow.U_Code
		#Check if we have already found this Ucode
		if pageorder not in ucodes:
			ucodes[pageorder] = 0
		ucodes[pageorder] += 1
		pdfname = pageorder + "_" + str(ucodes[pageorder]) + ".pdf"
		print(pdfname)
		if os.path.exists(strOutpath + pdfname):
			print("Error", pdfname)
		arcpy.mapping.ExportToPDF(mxd, strOutpath  + pdfname)
	del mxd

Highest Number of Persons Born in the UK, Living in Ireland-Census 2016

I was reading an article online the other day about Brexit and I got thinking about all the Irish people (myself included, at least for the next two weeks) that live in the UK. I’ve never heard much said about the people from the UK that live in the Republic.

With no surprise, the border counties contain the highest percentage of persons living in them who were born in the UK. So, the question now is, if we exclude the border counties (Donegal, Leitrim, Cavan, Monaghan and Louth) where in Ireland has the highest percentage of persons living there who were born in the UK?

I used the small area spatial unit for this analysis. The answer is, Templenoe, County Kerry. Templenoe is 6km to the west of Kenmare. Obviously, I can’t say for sure but I would be tempted to guess that part of the reason for this is the presence of the Ring of Kerry Golf Course. Twenty of the sixty-nine people who live there were born in the UK.

UK Born - Census 2016

Percentage Persons Born in the UK

Phoenix, Arizona

I was thinking the other day about the true size of Phoenix, Arizona and its sprawling suburbs. I wondered what this would look like overlaid on Dublin. The coordinate systems are different but the below overlay gives a good indication of its size in comparison to Dublin.

Phoenix Overlaid on Dublin

Phoenix Overlaid on Dublin

Commute to Work-Ireland

I was reading ‘Project Ireland 2040-National Planning Framework‘ and it got me thinking about what percentage of people in each ED commute for an hour or more to work. This is exactly the type of unsustainable living that needs to be avoided by promoting as much infill development as possible in existing urban centres. Below is a map I created that shows the commuting times that people face, obviously, it is important to bear in mind that the stark red colour still only equates to a maximum of 34% of people commuting for an hour or more. This is still just over one third, which is significant. Although not designed with the purpose in mind it gives a good indication of the functional urban area of the major cities (especially Dublin). Commuting Time Ireland-Census 2016





Python-Quick Graph

I’ve never really had cause to use Matplotlib before so over the weekend I took a quick look at it and how useful it actually is for creating quick graphs. I took the electricity connections dataset (used as a measure of new homes built, however rough) and created a simple line graph. Below is the code I used and the result.

import matplotlib.pyplot as plt

years1 = ['1975', '1976', '1977', '1978', '1979', '1980', '1981', '1982', '1983', '1984', '1985', '1986', '1987', '1988',
'1989', '1990', '1991', '1992', '1993', '1994', '1995', '1996', '1997', '1998', '1999', '2000', '2001', '2002',
'2003', '2004', '2005', '2006', '2007', '2008', '2009', '2010', '2011', '2012', '2013', '2014', '2015']

scores1 = [26892, 24000, 24548, 25444, 26544, 27785, 28917, 26798, 26138, 24944, 23948, 22680, 18450, 15654, 18068, 19539,
19652, 22464, 21391, 26863, 30575, 33725, 38842, 42349, 46512, 49812, 52602, 57695, 68819, 76954, 80957, 93419, 78027,
51724, 26420, 14602, 10480, 8488, 8301, 11016, 12666]


fig, ax = plt.subplots()
ax.plot(years1, scores1, marker='o')
ax.set(xlabel='Year', ylabel='Number of Connections')
plt.title("Ireland: Electricity Connections 1975-2015", fontsize=18)
ax.grid()
plt.xticks(years1, rotation=45)
plt.margins(0.01)
plt.show()

And here is the resulting graph:

Python Plot, Electricity Connections
ESB Connections-Ireland

The main strength I’ve seen from it is that it is very easily customisable as well as being a nice addition at various stages of a complex python script in order to error check a methodology in train.

Isochrones-Ireland and Australia

I was reading Topi Tjukanov’s fantastic post yesterday on how far you can drive in one hour from European capitals. This got me thinking, wouldn’t it be interesting to compare driving distance for somewhere in Ireland and somewhere in Australia. For Ireland I chose the geographic centre and for Australia I chose my fiancée’s home city of Perth. I used Digital Geography’s post on utilising the HERE API to generate isochrones for 2, 4 and 5.5 hours driving distances. Unless I’m mistaken, the API seems to max out at 5.5 hours (as measured in seconds) so that’s why 5.5 hours was my upper limit.

Interesting but not surprising to see that you can cover almost the entire of the island of Ireland in that time but it Australia it doesn’t look like much progress at all!

Ireland-Isochrone Map

Ireland-Isochrone Map

Perth-Isochrone Map

Perth-Isochrone Map

Ireland, A Country in Motion: Methodology

I promised late last year that I’d do a blog post explaining how I created the ‘Ireland in Motion’ commuting map. Well, this is that post!

The first thing to say is, that until the ’16 census results came out it wasn’t possible (as a member of the public) to create this type of map as the Central Statistics Office (CSO) just didn’t release the data. Before now (and is still the case) in order to access the full Place of Work, School or College data (POWSCAR) you must attend a training program and sign up to be an ‘Officer of Statistics’. The deciding factor for myself was that you have to be resident in Ireland, which I am currently not. You also have to be a ‘bona fide’ researcher.

So, imagine my delight when I found out that they were releasing an aggregated anonymised dataset for the entire country! The data is aggregated by electoral divisions (ED) and county level. The POWSCAR website where the data can be downloaded is located here. There are two important caveats when talking about this data, EDs where fewer than 10 persons commuted have been excluded and records where no work, school or college were able to be geocoded have been removed. Below is an extract from the CSO’s website showing the categories available.

RESIDENCE_ED_GUID Geographic Unique Identification (GUID) Code for origin Electoral Division (ED)
RESIDENCE_CSOED CSO ED code for origin ED
RESIDENCE_CSOED_LABEL Name of origin CSO ED
RESIDENCE_COUNTY County code for origin county
RESIDENCE_COUNTY_LABEL Name of origin county
POWSC_ED_GUID GUID for destination ED
POWSC_CSOED CSO ED code for destination ED
POWSC_CSOED_LABEL Name of destination ED
POWSC_COUNTY County code for destination county
POWSC_COUNTY_LABEL Name of destination county
COUNT Number of persons commuting

The downloaded zip file when extracted was a 42MB CSV file. CSVs are an ideal format because they are supported by a huge number of programs. I knew that for the type of map I was going to create that I wanted to use create straight lines between the centroids of each ED. The basic methodology I followed was as follows:

  1.  Download CSV, inspect and clean the data (remove any extraneous records).
  2. Download the ungeneralised shapefile of the EDs (available here).
  3. Use QGIS to create the polygon centroids of each ED.
  4. Use the VLOOKUP and concatenate functions in Excel to create well-known text linestrings for the commutes between each EDs.
  5. Use python to parse the CSV file and multiply each row by the number (count) of commutes between each ED. Each row represents one commute between two EDs.
  6. Load the CSV into QGIS and save as a shapefile.
  7. Use FME to load the shapefile file into a PostGIS database.
  8. Connect database to QGIS and create the map.

Detailed Methodology:

1 CSV:

The original number of commutes in the CSV was 2, 750, 239. The following records were removed:

A. The destination was within the same ED (478,884)

B. There was no fixed place of work (174,628)

C. Work/school from home (114,189)

D. Commute to Northern Ireland (9,336)

E. Commute overseas(!) (3,531) were removed.



This left the grand total of 1,969, 671 Commutes to be mapped.

2  Download Ungeneralised shapefile:

The ungeneralised shapefile was downloaded from here.

3 Use QGIS to Create the Polygon Centroids:

The centroids of each polygon was quickly calculated in QGIS.

4 Vlookup and Concatenate in Excel:

The attribute table of centroids was exported to Excel and the Vlookup and Concatenate functions were used to create the linestrings for individual commutes as shown below:

1001,1002,1,-6.92771,52.83721,-6.93919,52.83783,"LINESTRING (-6.92771 52.83721, -6.93919 52.83783)"

5 Python:

A simple python script was used to multiply each line string by the count, so that each individual commute would be represented by a separate line on the map.

6 QGIS-Load CSV:

The CSV file was quickly and easily loaded into QGIS and exported as a shapefile. A better method to do this would probably have been to use FME to load the CSV directly into PostGIS and that’s something I will bear in mind for the future.

7 FME Shapefile:

FME 2017 was used to load the shapefile to PostGIS, and a simple reproject was used to get the data into Irish Transverse Mercator (EPSG 2157).

8 Connect PostGIS to QGIS:

A PostGIS layer can be added in a few clicks from within QGIS. The advantage of using PostGIS is that it will load the 1.96 million lines a lot faster than a shapefile for example, shapefiles have their uses (widely supported for example) but they are an archaic format that will hopefully go the way of the Dodo (this is already happening with the support for Geopackage in QGIS 3 for example).



The above is a quick overview of how I carried out the data processing for the map. It’s remarkable that almost all the software used to create the map was open-source. I’d be curious to try and do it totally open-source (replace FME with OGR and Excel with LibreOffice Calc) but as I have a home use licence for FME and Office ’16 I decided to use those.

Ireland-A Country in Motion: 1.96 Million Commutes

I was inspired by Alasdair Rae’s excellent work here, here and here to attempt something similar for Ireland. Below is the fruit of my labour over the last number of weeks. It shows 1.96 million individual commutes from every electoral division in Ireland. Commutes within a single electoral division are excluded. The data comes from the Irish Central Statistics Office, OpenStreetMap and OSI opendata. I will post in detail in the coming days on the methodology I used for completing this. For now I hope you enjoy.

Here is a pdf with much higher resolution Ireland-A Country in Motion and the same pdf in Google drive.

I will also post a very high resolution PNG over the weekend that can be used to print a high quality image.

Ireland-A Country in Motion

Ireland-A Country in Motion
